AWH Silverline Construction Hotline 972.833.2856

Silverline Construction Activity Community Notification June 2020

Silverline Construction Activity Community Notification October 2020

Silverline Construction Alerts Notifications

4TH QUARTER COMMUNITY MEETING SERIES - SERIE DE REUNIONES COMUNITARIAS DEL CUARTO TRIMESTRE

COPPELL

Monday, November 9th – 6:30 to 8:30 p.m. 4th Quarter Community Meeting • Coppell / Cypress Waters • Phone #: 469-391-0632 • Conference ID: 667 107 367

Lunes 9 de noviembre, de 6:30 p.m. a 8:30 p.m. Reunión comunitaria del cuarto trimestre en Coppell / Cypress Waters • N.º de teléfono: 469-391-0632 • Identificación de la conferencia: 667 107 367

CARROLLTON

Wednesday, November 11th – 6:30 to 8:30 p.m. 4th Quarter Community Meeting • Carrollton • Phone #: 469-391-0632 • Conference ID: 629 119 187

Miércoles 11 de noviembre, de 6:30 p.m. a 8:30 p.m. Reunión comunitaria del cuarto trimestre en Carrollton • N.º de teléfono: 469-391-0632 • Identificación de la conferencia: 629 119 187

ADDISON

Thursday, November 12th – 6:30 to 8:30 p.m. 4th Quarter Community Meeting • Addison • Phone #: 469-391-0632 • Conference ID: 311 726 831

Jueves 12 de noviembre, de 6:30 p.m. a 8:30 p.m. Reunión comunitaria del cuarto trimestre en Addison • N.º de teléfono: 469-391-0632 • Identificación de la conferencia: 311 726 831

RICHARDSON

Monday, November 16th – 6:30 to 8:30 p.m. 4th Quarter Community Meeting • Richardson • Phone #: 469-391-0632 • Conference ID: 706 487 124

Lunes 16 de noviembre, de 6:30 p.m. a 8:30 p.m. Reunión comunitaria del cuarto trimestre en Richardson • N.º de teléfono: 469-391-0632 • Identificación de la conferencia: 706 487 124

PLANO

Tuesday, November 17th – 6:30 to 8:30 p.m. 4th Quarter Community Meeting • Plano • Phone #: 469-391-0632 • Conference ID: 322 006 889

Martes 17 de noviembre, de 6:30 p.m. a 8:30 p.m. Reunión comunitaria del cuarto trimestre en Plano • N.º de teléfono: 469-391-0632 • Identificación de la conferencia: 322 006 889

DALLAS

Wednesday, November 18th – 6:30 to 8:30 p.m. 4th Quarter Community Meeting • Dallas • Phone #: 469-391-0632 • Conference ID: 151 919 874

Miércoles 18 de noviembre, de 6:30 p.m. a 8:30 p.m. Reunión comunitaria del cuarto trimestre en Dallas • N.º de teléfono: 469-391-0632 • Identificación de la conferencia: 151 919 874

ABOUT

DART Silverline Regional Rail Design-Build Project

The 26-mile long, regional rail Silverline on the Cotton Belt Corridor extends from DFW Airport through the northern portion of the DART service area to Shiloh Road in Plano. The current alignment passes through the cities of Grapevine, Coppell, Dallas, Carrollton, Addison, Richardson, and Plano and has up to 11 proposed stations. The Silverline Project’s primary purpose is to provide passenger rail connections and service that will improve mobility, accessibility and system linkages to major employment, population and activity centers in the northern part of the DART Service Area. The Silverline Project will interface with three DART LRT lines: The Red Line in Richardson/Plano, the Green Line in Carrollton and the Orange Line at DFW Airport. Also at DFW Airport the project would connect to Fort Worth Transit Authority's TEX Rail Regional Rail Line to Fort Worth and the DFW Airport Skylink People Mover.

ABOUT

DART Cotton Belt Regional Rail Design-Build Project

The 26-mile long, regional rail Cotton Belt Corridor extends from DFW Airport through the northern portion of the DART service area to Shiloh Road in Plano. The current alignment passes through the cities of Grapevine, Coppell, Dallas, Carrollton, Addison, Richardson, and Plano and has up to 11 proposed stations. The Cotton Belt Project’s primary purpose is to provide passenger rail connections and service that will improve mobility, accessibility and system linkages to major employment, population and activity centers in the northern part of the DART Service Area. The Cotton Belt Project would interface with three DART LRT lines: The Red Line in Richardson/Plano, the Green Line in Carrollton and the Orange Line at DFW Airport. Also at DFW Airport the project would connect to Fort Worth Transit Authority's TEX Rail Regional Rail Line to Fort Worth and the DFW Airport Skylink People Mover.

TEAM AWH

Archer Western Herzog (AWH) is a joint venture between Archer Western Construction and Herzog Contracting Corp. We have come together to provide the Dallas Metroplex with the best value and lowest risk construction solutions through a team of local, committed and experienced specialists.

Archer Western is a nationally-leading general contractor—the largest bridge builder, 5th largest transit and rail builder and 3rd largest transportation contractor according to Engineering News Record (ENR). The company is a member of the Walsh family of companies, a 119-year-old family-owned business group (www.walshgroup.com).

herzog png

Herzog, founded in 1969, has become a national leader in the delivery of complex urban rail transit projects; the firm is ranked as the 6th largest mass transit and rail contractor and 116th as a Top 400 Contractors by ENR (www.herzog.com).

Together with our dedicated designer, Jacobs Engineering Group, Inc., AWH offers a proven team with unmatched transit experience working together. AWH has built or operated every current commuter rail system in Texas.

TEAM AWH

Archer Western Herzog (AWH) is a joint venture between Archer Western Construction and Herzog Contracting Corp. We have come together to provide the Dallas Metroplex with the best value and lowest risk construction solutions through a team of local, committed and experienced specialists.

Archer Western is a nationally-leading general contractor—the largest bridge builder, 5th largest transit and rail builder and 3rd largest transportation contractor according to Engineering News Record (ENR). The company is a member of the Walsh family of companies, a 119-year-old family-owned business group (www.walshgroup.com).

herzog png

Herzog, founded in 1969, has become a national leader in the delivery of complex urban rail transit projects; the firm is ranked as the 6th largest mass transit and rail contractor and 116th as a Top 400 Contractors by ENR (www.herzog.com).

Together with our dedicated designer, Jacobs Engineering Group, Inc., AWH offers a proven team with unmatched transit experience working together. AWH has built or operated every current commuter rail system in Texas.

PROJECT LOCATION

Silverline Community Engagement

Silverline Art & Design Program

Silverline Construction

D/M/WBE Procurement Opportunities

Active Request for Proposals (RFP)

Dart Silver Line Regional Rail Project - US 75 Pedestrian Bridge - Request for Proposal

Archer Western Herzog would like to request a proposal for the US 75 Pedestrian Bridge (#36P) on the DART Silver Line Regional Rail Project in Carrollton, Texas.

This request for proposal is for design, fabrication and delivery of a prefabricated weathering steel pedestrian bridge near US 75 and President George Bush Turnpike.

Please contact Garrett Cole (e-maill gcole@walshgroup.com) for bridge details and bid sheet. Archer Western Herzog is tentatively scheduled to take delivery of the prefabricated bridge in June 2021.

Proposals will be due by 3:00 pm September 18^th, 2020. They can be emailed to gcole@walshgroup.com or mailed to 1548 Valwood Parkway, Suite 118, Carrollton, Texas 75006.

Contact Garrett Cole, AWH Project Engr. e-maill gcole@walshgroup.com

Closed Request for Proposals (RFP)

Asbestos and Lead Base Paint Removal - Request for Proposal

Proposals will be due by 3:00 pm September 1^st, 2020 by 3:30P (CSReply with Interest: Friday July 31, 202T)

Archer Western Herzog would like to request a proposal for Asbestos Containing Material and Lead Base Paint removal on existing bridges for the DART Silver Line Regional Rail Project in Carrollton, Texas.

Please see attached standard details of survey, laboratory results, specifications and bid form to show how it needs to be priced. Work on the Asbestos and Lead Base Paint removal is expect to begin mid-September 2020

Contact Garrett Cole, AWH Project Engr. e-mailL gcole@walshgroup.com

Install concrete/brick pavers and components

Reply with Interest: Friday July 31, 2020 by 3:30P (CST)

You are invited by Archer Western Herzog to participate in the DART Silver Line Project RFP 07232020 – Delivery and Installation of Concrete/Brick Unit Pavers and Components . You can use the link below to access all bid information:

Instructions to Bidders:

Archer Western Herzog (AWH) is offering procurement opportunities to deliver and install concrete/brick paver and components for stations and parking lots on its AWH Cotton Belt “Silver Line” Regional Rail Project. Currently AWH is seeking pricing proposals, in compliance with Dallas Area Rapid Transit (DART) Authority STANDARDS for:

• Unit & Architectural Pavers

• Paver Marking

• Paver Sand Beds

• Grout

Instructions to Bidders: Partial bids for one or more items will be accepted.
Contact Rosa Peña, AWH Project Engr. e-mailL rpena@walshgroup.com

Ballast Walls Construction

Proposal Due: July 13, 2020 by 3:30P (CST)

You are invited by Archer Western Herzog to participate in the DART Silver Line Project Request for Proposal 013 – Ballast Walls. You can use the link below to access all bid information:

Instructions to Bidders:

Use this link to access all bid information - link:
https://app.box.com/s/atnl8ct22njtkkjkgnqlrkfihfmf4z6h
This solicitation includes the following work:
- Utility Locates
- Utility potholing if needed
- Trenching / Excavation of ballast wall footing
- Spoil removal / haul off
- Supplying and installing reinforcement
- Supplying and installing wall underdrain if required
- Supplying and placing concrete for first & second stage pour
- Forming of upper portion of ballast wall
- Curing and protecting concrete placements
- Pointing & patching as required
- Backfilling face of ballast wall
Bids should be emailed to Shane Stone sstone@walshgroup.com

Contact Shane Stine, AWH Project Engr. - emial:sstone@walshgroup.com

Ballast Hauling to Stockpile Locations

Proposal Due: June 24, 2020 by 3:00P

Archer Western Herzog (AWH) is offering procurement opportunities for hauling of ballast to stockpile locations for its DART Silver Line Project.

Instructions to Bidders:

Bid form includes quantities divided by track segment.
Ballast to be hauled from Martin Marietta Dallas Yard to designated stockpile locations.
See project map for segment locations.

Contact Colton Raymond, AWH Project Engr. - emial:craymond@walshgroup.com

Furnish & Install Traffic Signals and Illumination

Reply with Interest by: June 19, 2020 by 3:00P

Archer Western Herzog (AWH) is offering procurement opportunities for furnishing and installing Traffic Signals and Illumination for its DART Silver Line Project.

Instructions to Bidders:

Latest design phase drawings for each sub-segment and roadway are included in the bid packages.
Bid form will include quantities divided by road and track segment from latest design phase drawings.

For bid documents, contact Sid Mehta, AWH Project Engr. - emial: smehta@herzog.com

Silverline Street Sweeping Procurement

Proposal Due: June 19, 2020 by 3:00P

Archer Western Herzog (AWH) Silverline Regional rail Project is accepting bids for street sweeping, this will be on a as needed basis (Monday-Saturday 7am-5pm). The Project consist of 27-miles of light rail from DFW Airport to Plano.

Contact Shane Stone, AWH Project Engr. - emial:sstone@walshgroup.com

1234

Light Gauge Metal Framing - Furnish & Install

email Eddie

Interest Response Due: June 4 , 2020

Proposal Due: June 20, 2020

Archer Western Herzog (AWH) is offering procurement opportunities for fabrication, delivery, and installation of the Light Gauge Metal Framing for stations on its AWH Cotton Belt “Silver Line” Regional Rail Project. Currently AWH is seeking pricing proposals, in compliance with Dallas Area Rapid Transit (DART) Authority STANDARDS for Light Gauge Metal Stud Framing for Canopies and Light Gauge Metal Stud Framing for Pylons.

Contact Eddie Medina, AWH Project Engr. - emial:emedina@walshgroup.com

Structural Steel Coating/Painting

Interest Response Due: June 2, 2020

Proposal Due: June 19, 2020 (NEW DUE DATE)

Archer Western Herzog (AWH-JV) is requesting proposals for steel coating/painting at DART Silver Line Project. Unit price should include all costs associated with the required labor, supervision, equipment, tools, temporary and permanent materials to perform the scope of work. Subcontractor should provide bond and warranty, per DART warranty requirements. Required: Polyaspartic Urethane Single Coat System (Sherwin Williams Envirolastic 940 DTM Polyaspartic Urethane, or equal). Surface preparation – SSPC-SP10/NACE2. Work is scheduled for 2022

View Solicitation Package

Structural Steel Welding RFP

Response Due: May 28, 2020

Proposal Due: June 11, 2020

The scope of work consists of cut-off, weld and brace structural steel (H-Piles) at railroad bridges. Unit price should include all costs associated with the required labor, supervision, equipment, tools and welding rods to perform the scope of work. Permanent material will be provided by AWH.

View Solicitation Package

Guideway Flatwork RFP

Closed: April 15, 2020

Archer Western Herzog (AWH) is offering procurement opportunities for furnishing and installing guideway flatwork (concrete ditches, flumes, and slope protection) for its DART Silver Line Project

Stations Parking Lot Earthwork RFP

Closed: April 10, 2020

RFP Scope: Archer Western Herzog (AWH) is offering procurement opportunities for earthwork, utilities, drainage, flatwork, light pole, roadway pavement, and parking lot components for stations on its AWH Cotton Belt “Silver Line” Regional Rail Project.

Turnkey Crew Building RFP

Closed: February 28, 2020

RFP Scope: Archer Western Herzog (AWH) is offering procurement opportunities for scheduling, managing, and building of Crew Building components for stations on its AWH Cotton Belt “Silver Line” Regional Rail Project
